Wir haben viele Spezifikationen für Sie wählen als unten Liste.
Wie hohe Helligkeit, IPS/TN Blickwinkel, breite Arbeits temperatur, 800x48/1024x600 /1280x800 Auflösung, RGB / TTL / LVDS / MIPI-Schnitts telle
Widerstands fähige oder kapazitive Touch panel
HDMI-Platine, serielle Anschluss platine
..........
Für mehr details, klicken sie bitte unten Modell Nein oder kontaktieren sie mich unter Helen@kingtechlcd.com
Größe | Modell Nr. | Auflösung | Umriss (mm) | AA(mm) | Helligkeit | PIN | Schnitts telle | Betrachtung winkel | Arbeits temperatur | Speicher temperatur |
7,0" | PV07002LZR40B | 800*480 | 164,9*100*3,5 | 154,08*85,92 | 300 | 40 | 24-Bit-Parallel-Rg-Schnittstelle | 12 Uhr | -20 ~ 70 | -30 ~ 80 |
7,0" | PV0705YX50E | 800*480 | 164,9*100*5,7 | 154,08*85,92 | 400 | 50 | 24-Bit-Parallel-Rg-Schnittstelle | 12 Uhr | -20 ~ 70 | -30 ~ 80 |
7,0" | PV07019LZR40U | 800*480 | 164,9*100*5,7 | 154,08*85,92 | 1000 | 40 | 24-Bit-Parallel-Rg-Schnittstelle | 12 Uhr | -20 ~ 70 | -30 ~ 85 |
7,0" | PV07024LZR50Z | 800*480 | 164,9*100*5,7 | 154,08*85,92 | 1000 | 50 | 24-Bit-Parallel-Rg-Schnittstelle | 12 Uhr | -20 ~ 70 | -30 ~ 80 |
7,0" | PV07032LSB30H | 800*480 | 166,37*105,39*6,60 | 152,40*91,44 | 800 | 30 | 8Bit LVDS-Schnitts telle | Alle | -30 ~ 85 | -30 ~ 85 |
7,0" | PV07028LSB40D | 800*480 | 165*104,09*5,3 | 152,4*91,44 | 350 | 40 | TTL/RGB | Alle | -30 ~ 85 | -40 ~ 90 |
7,0" | PV07005YP40E | 800*480 | 165,00*104,54*5,20 | 152,40*91,44 | 430 | 40 | 18-BIT RGB | 12 Uhr | -20 ~ 70 | -30 ~ 80 |
7,0" | PV07034Y0140K | 1024*600 | 164,9*100*5,66 | 154,21*85,92 | 1000 | 40 | LVDS | Alle | -20 ~ 70 | -30 ~ 80 |
7,0" | PV07025LZR50A | 1024*600 | 164,90*100,00*5,66 | 154,21*85,92 | 1000 | 50 | RGB | Alle | <P>-20 ~ 70 | -30 ~ 80 |
7,0" | PV07031LZR30G | 1024*600 | 164,1*97,16*2,6 | 154,21*85,92 | 220 | 30 | MIPI | Alle | -10 ~ 60 | -20 ~ 70 |
7,0" | PV07026LZR50B | 1024*600 | 164,90*100,10*2,8 | 154,21*85,92 | 450 | 50 | TTL/RGB | Alle | -20 ~ 70 | -30 ~ 80 |
7,0" | PV07035H0140L | 800*1280 | 99,85*161,1*2,53 | 94,2*150,72 | 250 | 40 | MIPI | Alle | -20 ~ 70 | -30 ~ 80 |
